Essilor Gerber Kappa Patternless Lens Edger. The Essilor Kappa Lens Edger was sold and marketed by Gerber for many years, but always made by Essilor. Of the lens (Essilor patent). Polishing: flat edge. Technical SpecificaTionS tracer-Centerer-Blocker Edger Digital system.

. Essilor Edger Service Manual. If this is your first visit, be sure to check out the by clicking the link above. You may have to before you can post: click the register link above to proceed. To start viewing messages, select the forum that you want to visit from the selection below. In order to post new threads and items for sale in this forum, you will need to first purchase one of the OptiBoard Subscriptions available in under in your user. Disclaimer: Please note that OptiBoard provides the Optical Marketplace forum as a service to the eyecare industry.

However we do not guarantee the goods and services offered here nor can we vouch for the people making these offers. As with any buyer-seller relationship you will need to do your own research prior to purchasing. We are not responsible for any third-party transactions.

And finally, please do not post wholesale prices. This is a public forum and wholesale prices are not public information.

We have a manual, but honestly, we often have to call Gerber anyway. It's not that we can't read the manual, it hasn't had the info we needed in it when something broke. We do about 30 jobs a day, and have had it over 10 years now, and I must say it has just been adequate as far as not breaking down is concerned. We just had to do some electrical work on our gamma last week, had to order parts in from gerber, about a 3 hour install (we kept burning out fuses). For it's time it was a very good edger, but we have spent lots in repair and maintenance through the years.

We are having some problems with the Tracing table. When we put the Adapter for tracing lenses or formers the tracer still thinks it is tracing a frame.

It will not acknowledge the Adapter. I would still like the Service Manual if I could get one. John:cheers:Hey John, I think there is a switch that triggers when you have the jaws open all the way for the adapter. Its probably not working, unplugged, or out of adjustment. I remember that being the case on the Triumph tracers which is probably the same design. Your problem is that when the clamps close on the adapter, the encoder is not getting the proper measurement.

You have encoders for both the front and rear jaw assemblies. The clamps which do the measureing are the front right and rear left clamps. Check to see if either of these clamps have excessive play and if they do, the clamp peg may be broken of worn.

Essilor Kappa Edger Manual

You can try to wrap the black clamp cover with 'ONE' layer of electrical tape to take up the slack, so the clamp opening is closer to what the encoder needs to recognize the adapter. The clamp assemblies can be replaced, but are available only as a complete assembly with the encoders attached and cost about $500 a piece. The owner manuals do not address any service problems that are not simple calibration issues. Do not try to calibrate the tracing table with this problem, or you won't be able to trace frames either. The technical manuals are available.
